Clean Room Handheld Laser Airborne Particle counter for Lab
instrument
Handheld Particle Counter is used to detect the size and quantity
of particles in the air per unit volume of the clean environments.
It can quickly check or validate ISO Class 5-9 clean rooms and
controlled environments.
With LCD display, the instrument uses laser diode as the light
source. It has many features, such as slim design, light weight,
high precision, simple operation, micro computer control, and can
store and print sampling results. It is widely used in the
electronics, optics, chemistry, food and beverage, pharmacy and
sanitation, biology, precision machinery, aerospace, and other
fields.
| Outside Dim | 300*360*126 mm3(Wide*Deep*High) |
| Display | LCD |
| Weight | 0.6kg |
| Battery | (Lithium Ion Battery),7.2V,2200mAh |
| Power Source | Li-ion charger ,8.4V DC,1A:9-250V AC, 50-60Hz |
| Size Channels | 0.3, 0.5, 1, 3, 5, 10 μm |
| Flow Rate | 2.83L/min |
| Sample Time | 1s-99h |
| Cycles | 0-99 |
| Hold Time | 0-999sec |
| Delay Time | 0-99sec |
| Light source | Laser Diode |
| Zero Court | <=10min |
| Alarm | Low Battery ;100, 1000, 10000 Class /ISO |
| Coincidence Loss | 5%,2000000ps/cf |
| Operating Time | more than 5.5 hours |
| output | RS-232 to pc or printer via optional cable |
| Location Labels | 0-999 |
| Data Storage | 1000 Samples (With PC Software) |
| Environmental | 10degrees celsius-40degrees celsius ; Humidity: 20%-90% RH ;Atmosphere Pressure 86Kpa-106Kpa |
| Standard feathure | suitcase ;charger;sampling head;line of communication;communication
software ;Automatic Purifier |
| Optional component | External printer |
Parameter:
l 8 particle-size channels: 0.3, 0.5, 0.7, 1.0, 2.0, 3.0, 5.0,
10.0(μm)
l Sample Period : 1 Sec~3599 Sec(5L-3000L)
l Self-clean Time : ≤10min
l Operating Environment : Temperature 10~35°C,Relative Humidity
≤75%
l Output : Built-in Printer
l Light source : Laser diode (30,000 hours mean time between
failure)
l Max permissible sampling concentration :35.000PCS/L
l Dimension (W×L×H):215×500×240(mm)
l Power Rating : 250W
l Weight : 8KG
l Power Supply : 220V±10%,50Hz±2Hz
l Data conversion (ft3 and m3)
l Accessory: Case, Operation manual, Factory inspection report,
Filter, Power line, Tripod ,Printing paper, Fuse
