    Mini Pleated Terminal HEPA Filter , 2x4 HEPA Filter H13 With HV Media

    Ask Lasest Price
    Brand Name : indair
    Model Number : ID-MF-02
    Certification : CE,UL,ISO
    Price : negotiable
    Supply Ability : 1000 PCS PER DAY
    • Product Details
    • Company Profile

    Mini Pleated Terminal HEPA Filter , 2x4 HEPA Filter H13 With HV Media

    4*2 feet Mini-Pleated HEPA Air Filter with HV Media for clean room for GMP with CE H13

    Product Description

    High efficiency particulate air (HEPA), originally called high-efficiency particulate absorber but also sometimes called high-efficiency particulate arresting or high-efficiency particulate arrestance, is a type of air filter. Filters meeting the HEPA standard have many applications, including use in clean rooms for IC fabrication, medical facilities, automobiles, aircraft and homes. The filter must satisfy certain standards of efficiency.

    To qualify as HEPA by industry standards, an air filter must remove (from the air that passes through) 99.97% of particles that have a size greater-than-or-equal-to 0.3 µm. Although the ASME industry standard is not published by any government, it is recognized as an authoritative standard by many governments.

    HEPA was commercialized in the 1950s, and the original term became a registered trademark and later a generic term for highly efficient filters.


    Product Details
    Type: Mini-pleat HEPA filter
    Gasket: CR,EVA,EPDM,PU

    Frame: Extruded aluminum. Face guard: Baking finish

    Separator: Hot-melt beads. Filter class(EN1822):H12, H13,H14

    Media: H&V Glass fiber, PTFE
    Recommended final pressure drop.: 500 Pa.

    Temperature / Humidity: 70°C / 100% RH


    Why choose us

    1, Advanced and new machinery equipment

    2, More than 10 years’ experience in filtration field

    3, Professional exporting sales with 7 years’ experience

    4, Closed biggest port ,Shenzhen port

    5, Sincere honest and trustworthy


    Standard Size

    We not only produce all kinds of different normal size Mini-pleat HEPA filter,but also accept all kinds of customized
    size Mini-pleat
    HEPA filter.Please choose what size you want to buy refer to the below table,

    Model Dimensions
    (W×H×D) mm
    Filter grade
    EN1822
    Airflow / pressure drop m³/h / Pa (± 15%)Unit
    volume
    610x610x50H13603/1300.041
    1170X1170X50H132218/1250.082
    1170x570x50H131080/1300.073
    610x610x70H13603/1100.026
    1170X1170X70H132218/1050.052
    1170x570x70H131080/1100.046
    610x610x90H13603/850.033
    1170X1170X90H132218/800.066
    1170x570x90H131080/850.060
    610x610x50H14603/1400.041
    1170X1170X50H142218/1350.082
    1170x570x50H141080/1400.073
    610x610x70H14603/1200.026
    1170X1170X70H142218/1150.052
    1170x570x70H141080/1200.046
    610x610x90H14603/950.033
    1170X1170X90H142218/900.066
    1170x570x90H141080/950.060
