    H12 Mini Pleated HEPA Filter For Food And Beverage Industry

    Ask Lasest Price
    Brand Name : INDAIR
    Model Number : ID-PF-06
    Certification : CE,UL
    Price : negotiable
    Supply Ability : 1000 Pcs Per day
    • Product Details
    • Company Profile

    H12 Mini Pleated HEPA Filter For Food And Beverage Industry

    Indair Series HEPA Air Filter Performance:

    Hepa filters are mainly used to catch particulate dust and various suspended substances below 0.3um.

    The basic requirements are high filtration efficiency, low flow resistance and continuous use for a long time to reduce the cost of consumables in the later stage.


    Use made of super fine glass fiber paper, offset paper, aluminum membrane materials, such as partition board, with wooden frame aluminum alloy agglutination, the use of special silicone rubber, no smell, not surface hardening, long time also won't have crack, stable chemical performance, corrosion resistance, can absorb heat bilges cold shrink stress without cracking, moderate hardness, good elasticity.

    Each unit is tested by sodium flame method, with high filtration efficiency, low resistance, large dust capacity and other characteristics.


    Application: HEPA-/ULPA filter for clean rooms and LAF benches.Type: HEPA-/ULPA-Filter.Frame: Extruded and anodised aluminum.
    Gasket: Polyurethane.Media: Membrane (ME).Efficiency acc. EN 1822:2009: H14, U15. MPPS Efficiency acc. EN 1822:2009: ≥99,995%, ≥99,9995% at MPPS.Recommended final pressure drop: 2x initial pressure drop.Maximum pressure drop: MD: 500 Pa; MX: 600 Pa.
    Temperature/Humidity: 8C / 100% RH. Remarks: Individually scantested acc. EN 1822:2009 with protocol and packed in PE-foil.


    Advantages:


      Mini-pleat design lowers operating costs.
      Knife-edge design ensures perfect seal.
      Efficient leak and scan test.
      Low off-gassing components.
      Wide range efficiencies.
      Lightweight and compact.


    Standard Size

    We not only produce all kinds of different normal size Mini-pleat HEPA filter,but also accept all kinds of customized
    size Mini-pleat
    HEPA filter.Please choose what size you want to buy refer to the below table,

    Model Dimensions
    (W×H×D) mm
    Filter grade
    EN1822
    Airflow / pressure drop m³/h / Pa (± 15%)Unit
    volume
    610x610x50H13603/1300.041
    1170X1170X50H132218/1250.082
    1170x570x50H131080/1300.073
    610x610x70H13603/1100.026
    1170X1170X70H132218/1050.052
    1170x570x70H131080/1100.046
    610x610x90H13603/850.033
    1170X1170X90H132218/800.066
    1170x570x90H131080/850.060
    610x610x50H14603/1400.041
    1170X1170X50H142218/1350.082
    1170x570x50H141080/1400.073
    610x610x70H14603/1200.026
    1170X1170X70H142218/1150.052
    1170x570x70H141080/1200.046
    610x610x90H14603/950.033
    1170X1170X90H142218/900.066
    1170x570x90H141080/950.060
