On Floor Stainless Steel Pass Box , Air Shower Pass Box 920 x 850 x 1580 mm

Ask Lasest Price
Brand Name :	indair
Model Number :	ID-PB-07
Certification :	CE,ISO
Price :	negotiable
Supply Ability :	100 unit per day
Delivery Time :	15 work days

Add to Cart

Product Details
Company Profile

On Floor Stainless Steel Pass Box , Air Shower Pass Box 920 x 850 x 1580 mm

On Floor Dynamic Pass Box Pass Through Window with air shower for pharmaceutical factory

FUNCTION

INDAIR Laminar Air Flow (LAF) Pass Box functions as an effective solution for material transfer between different classified areas. It is designed to prevent air turbulence and minimize entry of contaminants when products or items enter the critical area. With interlocking mechanism, two doors of ACDT LAF Pass Box cannot be open simultaneously during the material transferring process, eliminating cross contamination. The stable down-flow reduces the particulates on material surfaces and achieves Class 100 (ISO 5) air cleanliness.

FEATURE

ü A variety of configuration and size meet any application.

ü Reliable interlock mechanism prevents cross-contamination.

ü Highly-efficient air filtration by HEPA or ULPA filter.

ü UV light with elapsed timer.

ü Internal coving for easy cleaning.

ü Low vibration, low noise (<70 dB).

ü Internal R angle Integrated

ü Silicon compression sealant

ü View window included.

ü PIC/S compliant.

ü Customization is available to meet customer’s requirement.

Static Pass Box
* Double walled construction
* Electro-magnetic interlocking view panels
* Mechanical/Pneumatic interlocking

Dynamic Pass Box
* Two stages filtration
* Statically & dynamically balanced motor-blower
* Electro-megnetic interlocking

Product and Solution Selection

1. Outer and Inner Dimension. The outer dimension should be decided according to clean room design, while the inner dimension is for the operation area.

2. The dynamic passbox is suit for the transmission happened from lower cleanliness environment to higher cleanliness environment. If the transmission happens between same cleanliness, static passbox is recommended.

3. The direction of door opening should be considered according to the position of passbox.

4. SUS 304 is recommended for the casing of passbox.

5. If the transfer cart is required in clean room, the floor-mounted passbox is recommended.

MODEL	BC-060608T
OUTTER SIZE(W x D x H)	760 x 660 x 1350 mm
INNER SIZE(W x D x H)	600 x 600 x 800 mm
CLEAN CLASS	ISO CLASS 5 (100)
AIR FLOW(m/s)	0.45m/s / 22 m/s
uv LIGHT	Philips
qty of nozzle	4
air shower time(s)	12 Second(0-99Second could changable)
efficiency	H13 HEPA filter G4 Pre-Filter
Medium	Hepa Filter: Mini Pleated fiberglass:
material	sus304,201,202
Power Supply	220V AC 1PH 50 Hz
Power	0.30 kW
G.W. (kg )	274 kg
N.W.(kg )	150 kg
SIZE(LxWxH,mm)	920 x 850 x 1580 mm
