Stainless Steel Manufacturer of Pharmaceutical Weighing Booth
Dispensing sampling booth
Pharmaceutical Weighing Booth, Laminar Flow Clean Booth
This is a clean room full service construction under GMP request. A
Cleanroom or clean room is an environment, typically used in
manufacturing or scientific research, that has a low level of
environmental pollutants such as dust, airborne microbes, aerosol
particles and chemical vapors. More accurately, a cleanroom has a
controlled level of contaimination that is specified by the number
of particles per cubic meter at a specified particle size. To give
perspective, the ambient air outside in a typical urban environment
contains 35,000,000 particles per cubic meter in the size range
0.5um and larger in diameter, corresponding to an ISO9 cleanroom,
while an ISO1 cleanroom allows no particles in that size range and
only 12 particles per cubic meter of 0.3um and smaller.
Using Environment and Conditions:
Temperature: 5 ℃ -40 ℃
Relative humidity: less than 85%
Atmospheric pressure: 86kPa-106kPa
Power supply: AC220V, single phase, 50Hz.
Standard Model Technology Parameter:
Quicky Detail:
Purification rank: Class100
Three Step Filtration System
Fluid seal Mini-pleats HEPA filter
99.995%@0.3um H13
GMP Standard with DOP port testing
Air speed:0.3-0.6m/s
Power: 380V/60HZ or 415V/50HZ
Applications: dispensing booth subdivision of powder of liquids, charging and
offloading materials to reactors, fluid bed dryers, granulators,
filter dryers, glass ware skids in clean rooms and so on.
Main Features
1. Unique designed air duct effectively controls the noise.
2. Smooth transitions of wall and ground can eliminate the blind
angle.
3. Differential pressure gauge is equipped to real-time monitor the
filters.
4. Intelligent control mode and alarm system ensure the reliability
of running.
5. Automatic changeable frequency system monitors the air velocity
to ensure its stability in the work area.
6. Uniform flow design of main working area can protects the
operators and prevent environmental pollution and cross
contamination of products.
7. Dispensing Booth(Sampling or Weighing Booth) has primary
filters, medium efficiency filters and HEPA filters to keep air
cleanliness of work area.
| Item No. | ID - FT3A43R | ID - FT3A66R | ID - FT3A97F | ID - FT4A43P |
| Material | SUS 304 Fingerprint Proof |
| Roof | Uniform flow film |
| Power | AC 380V/3ph+1N+1E |
| Clean Class | ISO CLASS 5 (100 class) |
| Outter Size (W x D x H) | 1500 x 1500 x 2600 mm | 1900 x 2600 x 2600 mm | 6100 x 2800 x 2900 mm | 1500 x 1500 x 2600 mm |
| Inner Size (W x D x H) | 1400 x 1000 x 2000 mm | 1800 x 1800 x 2000 mm | 6000 x 2200 x 2200 mm | 1400 x 1000 x 2000 mm |
| Efficiency | G4(EN779) | G4(EN779) | G4(EN779) | G4(EN779) |
| F8(EN779) | F8(EN779) | F8(EN779) | F8(EN779) |
| H14(EN1822) | H14(EN1822) | H14(EN1822) | H14(EN1822) |
| Working Size (L x W x H) | 800*600*800 mm | 1200*600*800 mm | N.A | 800*600*800 mm |
| Service Rating | 2.4 kW | 4.6 kW | 11.2W | 3.2 kW |
| Average Wind Velocity | 0.36m/s~0.54m/s |
| Touch Screen | Siemens |
| PLC | Siemens |
| PAO Test Size | Φ8MM |
| MANOMETER | DWYER |
| Operation Separate | PC 10” glove |
| Air Velocity Transducer | 0-1 m/s | optional |
| Light | ≥400 Lux | ≥300 Lux |
| Anti-hazard classificaiton | N.A | EX d II BT4 |
| Outlet | 220V/1P,10A IP66 | 220V/1P,10A EX dII BT4 |
