Static type Cleanroom transfer wind Pass Box Pass Through Window
with CE UL for GMP
Pass box as an auxiliary device of a clean room, mainly used to
deliver small objects between clean area and clean area , unclean
area and clean area . In order to reduce doors opening times of
clean room, to mixmum reduce the pollution of the clean area.
Factory test include:
--appearance testing
--functional test and visual inspection
--electrical safety tests
--air velocity testing
--noise testing
Warranty:
Our equipment is warranty for 1 year excluding consumable parts and
accessories.
All equipment is shipped with a comprehensive use’s manual complete
with a report documenting all test procedures.
Additional IO/OQ/GMP document is available upon request.
Contact our sales representative for specific warranty details or
document request.
Consumable parts illustration:
1: Pre-filter: each one should be replacement in each 6 month, but
it can refresh no more three times.
2: HEPA air filter: each one should be replacement in each half and
one years.
Standard export packing:
--Stretch film strapped whole cabinet,
--Foam inside protected,
--Plywood case solid fixed
--European standard bottom tray
Product and Solution Selection
1. Outer and Inner Dimension. The outer dimension should be decided
according to clean room design, while the inner dimension is for
the operation area.
2. The dynamic passbox is suit for the transmission happened from
lower cleanliness environment to higher cleanliness environment. If
the transmission happens between same cleanliness, static passbox
is recommended.
3. The direction of door opening should be considered according to
the position of passbox.
4. SUS 304 is recommended for the casing of passbox.
5. If the transfer cart is required in clean room, the
floor-mounted passbox is recommended.
| MODEL | BC-060608T |
| OUTTER SIZE(W x D x H) | 760 x 660 x 1350 mm |
| INNER SIZE(W x D x H) | 600 x 600 x 800 mm |
| CLEAN CLASS | ISO CLASS 5 (100) |
| AIR FLOW(m/s) | 0.45m/s / 22 m/s |
| uv LIGHT | Philips |
| qty of nozzle | 4 |
| air shower time(s) | 12 Second(0-99Second could changable) |
| efficiency | H13 HEPA filter G4 Pre-Filter |
| Medium | Hepa Filter: Mini Pleated fiberglass: |
| material | sus304,201,202 |
| Power Supply | 220V AC 1PH 50 Hz |
| Power | 0.30 kW |
| G.W. (kg ) | 274 kg |
| N.W.(kg ) | 150 kg |
| SIZE(LxWxH,mm) | 920 x 850 x 1580 mm |
